MEGATRON® III PV FOR MICS – MICRO INCISION
CATARACT SURGERY
The optimum MICS settings of the advanced
MEGATRON® S3 System with Cool Flash Mode
Technology
have now been transferred to the new
MEGATRON® IIIPV as well.
MEGATRON® IIIPV Phaco Technology signifi
cantly reduces the ultrasonic power emitted:
on average,
when compared to the traditional pulse mode,
the ultrasonic time is reduced by 50%!
By means of micro-incisions, the fi ne
modulated and effective microbursts allow
for the the emulsification
without burning of even the hardest nuclei.
The tight incisions reduce the occurrence of
turbulences and
chatters.
This new technology yields excellent post-op
results, such as clearer corneas and faster
visual recovery because
the smaller incisions and reduced ultrasonic
energy and decreased occurrence of
turbulences lessen endothelial
cell loss and trauma.
 |
MEGATRON®
PERISTALTIC PUMP
* Realistic Venturi Effect
* Ideally suited for high vacuum phaco
”Magnetic” fragment aspiration |
|
| |
|
 |
GEUDER®
ULTRASONIC HANDPIECES
* Constant stroke during hand piece
lifetime
* Multilayer handpieces for perfect effi
ciency and
long lifetime
* Only one handpiece needed for phaco,
cool phaco and fragmentation |
| |
|
 |
MEGATRON® FOOTSWITCH
* Dual-linear control
* Remote control of console
* Remote control of infusion pole |
| |
|
 |
MINI MEGA ULTRASONIC TIP1
* Unique patented design
* Emulsifi cation inside the tip
* Signifi cant reduction of phaco power
and time
* Improved fl uidics for high vacuum
phaco and
enhanced control of nucleus removal
|
 |
REAL-TIME VAC SENSOR
* Real-time vacuum sensor and air free
aspiration line for maximum anterior
chamber stability
|
| |
|
 |
MICS INSTRUMENTS3
* Widest range of MICS instruments
* 20 gauge forceps and scissors
* MICS diamond and disposable knives
|
| |
|
 |
IRRIGATING CHOPPERS
AND BI MANUAL IRRIGATING /
ASPIRATING HANDPIECES2
* Widest range of accessories for
systems
* Irrigating Instruments provide high
infusion |
ACTUAL VENTURI EFFECT
* No external pneumatic assistance
* Extremely short vacuum rise time of 0.5
seconds possible, allowing for
* “Magnetic” aspiration of fragments when US
and I/A tips are placed centrally
ALL TYPICAL PERISTALTIC ADVANTAGES
* MSA – Membrane Soft Aspiration for total
vacuum control of the retina
* Vacuum and fl ow rate can be controlled
separately
* Minimum loss of fl uid through anterior
chamber
* Pulsed as piration
AND MORE …
* Oil injection pressure adjustable to
accommodate different viscosities
* High vacuum phaco for use with GEUDER®
Mega-Tips
* Can be programmed for several surgeons and
multiple procedures
* Footswitch functions can be programmed to
suit individual preferences
* The infusion stand can be controlled
electronically
* Audiovisual control signals are available
for infusion, aspiration, vacuum,
ultrasonic power and diathermy
* No expensive cassette system, resulting in
low average costs per operation
* Real-time vac sensor sterilizable at 134º
C (273.2º F)
* Automatic self-test and tuning of
functions at activation
* Remote Control
TECHNICAL DETAILS
|
Measurements: |
B/W
500, H 150,T/D 370 mm W 20, H 6, D 14.8
in. |
|
Weight: |
19
kg (41.8lb.) |
|
|
Voltage: |
90
– 250 V |
|
|
|
Power frequency: |
47
– 63 Hz |
|
|
|
Power: |
400
W |
|
|
|
|
|
|
|
|
|
ASPIRATION |
|
|
|
|
Flow rate: |
1 –
50 ml |
|
|
|
Vacuum: |
1 –
550 mmHg |
|
|
Flow rate pulsation: |
7
Hz |
|
|
|
Excessive aspiration: |
0 –
100% +/- 10 ml |
|
|
Vacuum rise with |
|
|
|
|
venturi effect: |
5 –
0.5 sec. |
|
|
|
|
|
|
|
|
VITRECTOMY |
|
|
|
|
Functional principle: magnetic |
|
|
|
|
Stroke: |
10
– 2000 imp/min |
|
|
Functional principle: |
pneumatic |
|
|
|
Nominal pressure: |
1.4
bar (20 PSI) |
|
|
Stroke: |
10
– 600 imp/min |
|
|
|
|
|
|
|
|
PHACO |
|
|
|
|
|
Frequency: |
27
– 55 kHz |
|
|
Pulsation: |
Cool Flash Technology |
|
|
|
|
|
|
|
INFUSION |
|
|
|
|
Bottle Height: |
max. 99 cm (39 in.) |
|
|
|
|
|
|
|
|
DIATHERMY |
|
|
|
|
Power: |
|
0
– 15 W at 125 Ohms |
|
Frequency: |
1.5
MHz |
|
|
|
Pulsation: |
|
3
Hz |
|
|
|
